3m High Speed HDMI Cable with Ethernet A/A M/M White
Code: ICOC HDMI-4-030WH    Barcode: 8057685306929

   Supplier Code: 306929

Available

3m High Speed HDMI Cable with Ethernet A/A M/M White

Certificazioni: RoHS
Anni di Garanzia: 3
Tipo connettore B: HDMI-A
Connettori dorati: Yes
Risoluzione massima: 4K (2160p)
Altri Standard Supportati: 3D
Altri Standard Supportati: Full HD (1080i/p)
Altri Standard Supportati: HD ready (720i/p)
Altri Standard Supportati: HDCP
Choose a different Option:

• High Speed ​​HDMI Cable with Ethernet M / M 3m
• Gold-plated connectors 19-pin HDMI A / HDMI A 19-pin
• Supports Internet via HDMI (HEC)
• Maximum resolution: 4K Ultra HD 4096x2160
• 3D support with a resolution beyond 1080p and Deep Color
• Support for Audio Return Channel (ARC)
• High-speed, two-way communication up to 100 Mbps
• Bandwidth: 18 Gbps - Frequency: 600 MHz

    Description

    Details

    • Cable based on a new technology that offers the best data transmission between your HDMI source and HDMI display. The five twisted pairs offer better transmission of data between devices
    • Triple shielded with resistant connectors for better performance to optimize the signal integrity of the data, even in the worst of installation subject to interference EMS
    • Certificate ATC, this cable is fully compliant with the requirements of the HDMI standard worldwide. All cable materials are 100% RoHS compliant and lead-free
    • Connections: HDMI 19-pin male to HDMI 19-pin male
    • High-speed, two-way communication up to 100 Mbps
    • Supports HD resolutions beyond 1080p and Deep Color
    • Compliant with HDMI High Speed
    • Molded PVC
    • HDMI Ethernet Channel: supports Internet via HDMI (HEC)
    • Audio Return Channel: Allows an HDMI connected TV with a built-in tuner to send audio data "upstream" to a surround audio system, eliminating the need for a separate audio cable
    • Supports 3D protocols defines input / output for major 3D video formats, even for gaming and 3D home theater applications
    • Supports 4K Ultra HD 4000x2000 resolution: Enables video resolutions far beyond 1080p, supporting next-generation displays

    <b> Basics </ b>
    • Bandwidth: 18 Gbps
    • 600 MHz
    • Supports HEC
    • Compliant with HDMI 2.0 and earlier
    • Length: 3 meters

    <b> Connectors and Cable </ b>
    • 2 x HDMI 19-pin male
    • Gold-plated Contacts
    • Molded PVC boot
    • Shielded, braid and aluminum foil
    • internal conductors AWG 30
    • Cable diameter: 6.0 mm

    <b> Features </ b>
    • Supports YCbCr 4: 2: 0
    • Supports 32-channel audio
    • Supports 1536 kHz audio
    • Supports 4 audio streams
    • Supports 2 audio streams
    • Supports display 21: 9

    <b> Electrical Information </ b>
    • Current rating: 0.5 A DC
    • Supports voltage 300 V DC
    • Insulation resistance: 50 MOhms
    • Conductive resistance: 2 Ohms

    <b> Standards and Certifications </ b>
    • UL 20276
    • ISO 9002
    • RU

    <b> Package Contents </ b>
    • High Speed ​​HDMI Cable with Ethernet Channel 3 m
    data sheet
    generale
    Brand
    Techly
    Barcode
    8057685306929
    Weight
    0.1500
    Certifications
    RoHS
    Years of Warranty
    3
    Codice Fornitore
    306929
    specifiche
    Typology
    HDMI High Speed con Ethernet
    Length
    3 m
    Connector A Type
    HDMI-A
    format A connector
    male
    Connector B Type
    HDMI-A
    format B connector
    male
    Headphone connectors
    Yes
    Cable shielding
    Doble
    Shielding type
    Braid and aluminum foil
    Cable size (AWG)
    30
    Color
    White
    specifiche tecniche
    Cable rate
    600 MHz
    Maximum resolution
    4K (2160p)
    Maximum bandwidth per channel
    18 Gbit/s
    Color space support
    x.v. Color
    Audio Standard Supportati
    Dolby Digital/Plus , Dolby TrueHD , DTS-HD Master Audio , DVD-Audio , SA-CD
    Other Standards Supported
    3D , CEC , Full HD (1080i/p) , HD ready (720i/p) , HDCP , HEC (HDMI Ethernet Channel), SDTV (480i/p), Ultra HD 4K (2160i/p)
