3X1 SDI Switcher

Cod: IDATA SDI-31

Barcode: 8051128104875

Supplier Code: 104875

Weight: 0.410 Kg

Min. sale unit: 1 Pcs

Package pcs: 20 Pcs

Cod
IDATA SDI-31
Barcode
8051128104875
Supplier Code
104875
Weight
0.410 Kg
Min. sale unit
1 Pcs
Package pcs
20 Pcs
  • 3X1 SDI Switcher
  • Switch 3 Ways SDI Sources to One Output instantly
  • Control by IR remote or from front panel selector buttons; with memory function
  • Input: 3xBNC; output 1xBNC
  • SDI signal format: SD-SDI HD-SDI 3G-SDI
  • Supports max resolutions output: 1080p@24@25@30@50@60Hz
  • Support SD-SDI (270Mbps), HD-SDI (1.485Gbps) and 3G-SDI(2.97Gbps) video format at video speed rate: 143-2970Mb/S
  • Convenient switching methods, switching is able to accomplish by 2 ways: by using the optional IR remote or the front panel selector button
Description
IDATA SDI-31 3x1 SDI Switcher allows any one of three high-bandwidth 3G-SDI, HD-SDI or SDI sources to be switched to a single output without a switching delay or loss of signal quality. Ideal for cutting equipment costs in the studio by enabling shared signal routing. This broadcast-quality switcher accepts supports source resolutions up to 1080p and has convenient switching methods.

Features
  • Switch 3 Ways SDI Sources to One Output instantly
  • Control by IR remote or from front panel selector buttons; with memory function
  • Input: 3xBNC; output 1xBNC
  • SDI signal format: SD-SDI HD-SDI 3G-SDI
  • Supports max resolutions output: 1080p@24@25@30@50@60Hz
  • Support SD-SDI (270Mbps), HD-SDI (1.485Gbps) and 3G-SDI(2.97Gbps) video format at video speed rate: 143-2970Mb/S
  • Convenient switching methods, switching is able to accomplish by 2 ways: by using the optional IR remote or the front panel selector button
Technical Specifications
  • Backwards compatible with SDI and HD-SDI
  • Supports NTSC, PAL, and all HD formats
  • Plug-and-Play Installation
  • Power Supply: DC5V
  • SDI input: BNC x 3
  • SDI output: BNC x 1
  • SDI standards: compatible with SMPTE424M, SMPTE292M e SMPTE259M-C
  • SDI signal format: SD-SDI-HD-SDI 3G-SDI
  • SDI speed rate: 143-2970Mb/S
  • SDI impendance: 75Ω
  • SDI input/output resolution: 480i@60Hz, 576i@50Hz, 720p@24@25@30@50@60Hz, 1080i@50Hz 1080i@60Hz, 1080p@24@25@30@50@60Hz
  • SDI signal output Amplitude: 800mVp-p
  • Power Consumption: ≤2W
  • Dimensions: 130 x 77 x 24 mm
  • Temperature environment: da 40°C a 60°C
Package contents
  • 3X1 SDI Switcher
  • IR remote control
  • Power adapter
  • User manual
Data sheet
general
Brand Techly Np Barcode 8051128104875
Color Black Codice Fornitore 104875
input
Connector A Type SDI format A connector -
Number A Connector 3 Altri Connettori Input 1 x Alimentatore
output
Connector B Type SDI format B connector -
Number B Connector 1
technical specifications
Typology Switch Max Video Resolution 1080p
max bandwidth (MHz) - Deep Color -
HDMI - HDCP -
3D compatible - Supported audio standards -
Transmission Distance -
power supply
Power supply Requested (included) Consumo energetico ≤2W
dimensions
Width 130 mm Height 24 mm
Depth 77 mm Weight 0.4100
The package includes • Switch SDI 3 Porte • Telecomando • Adattatore • Manuale d'istruzioni
