Additional receiver for Powerline Extender IDATA EXTPL-380P
Code: IDATA EXTPL-380PR    Barcode: 8054529021628

   Supplier Code: 021628

Expected arrival 24/09/2021

Additional receiver for Powerline Extender IDATA EXTPL-380P

Tipo connettore A: C7 - 2 poles
Tipo connettore B: HDMI
HDCP: Yes
info Request information
Choose a different Option:

• Receiver for additional HDMI extender HdbitT
• Easy to install, thanks to auto pairing just connect it to the existing electrical outlet and is coupled to the transmitter automatically
• High Definition Full HD 1080p
• Data transfer powerline up to 300 meters in the same network
• It supports the innovative IR 360 °, allowing users to remotely control the HDMI source side HDTV
• Infrared Extender
• Supports HDbitT
• Supports resolutions up to 1920x1080 @ 60i / 50i / 23.98p / 24p
• Transmission distance up to 300 meters for normal applications
• A transmitter can work with four receivers simultaneously
• Supports remote control from the source
• Incorporates technology Home Plug AV controller with 200 Mbps PHY
• Supports optimal QoS for streaming video
• 40 levels of security protection from electricity

Technical specifications
• HDMI signal fully compatible with HDCP
• Transmission Protocol HDbitT
• Resolution: 480i 60Hz, 60Hz 480p, 576i 50Hz, 50Hz 576p, 720P 50HZ, 720P 60HZ, 1080i 50Hz, 1080i 60HZ, 1080P 50HZ, 1080P 60HZ
• Transmission distance: up to 300 meters at 1080p @ 60Hz with a proper electric power plant
• Infrared remote control: supports 20 ~ 60KHZ
• Input voltage: 100 / 240V AC
• Power consumption: 7W
• Housing material: plastic non-combustible
• Safety against electrical damage: coupling circuit with fuse and ESD protection, tested for 24 days, 7 hours of work a day

Dimensions
• Width 150 mm
• Height 25 mm
• Depth 92.7 mm

Package Contents
• 1x Receiver extender
• 1x Power Cable 100 / 240V AC
• 1x IR Receiver
• 1x User Manual

Accessories
    Description

    Details

    • Receiver for additional HDMI extender HdbitT
    • Easy to install, thanks to auto pairing just connect it to the existing electrical outlet and is coupled to the transmitter automatically
    • High Definition Full HD 1080p
    • Data transfer powerline up to 300 meters in the same network
    • It supports the innovative IR 360 °, allowing users to remotely control the HDMI source side HDTV
    • Infrared Extender
    • Supports HDbitT
    • Supports resolutions up to 1920x1080 @ 60i / 50i / 23.98p / 24p
    • Transmission distance up to 300 meters for normal applications
    • A transmitter can work with four receivers simultaneously
    • Supports remote control from the source
    • Incorporates technology Home Plug AV controller with 200 Mbps PHY
    • Supports optimal QoS for streaming video
    • 40 levels of security protection from electricity

    Technical specifications
    • HDMI signal fully compatible with HDCP
    • Transmission Protocol HDbitT
    • Resolution: 480i 60Hz, 60Hz 480p, 576i 50Hz, 50Hz 576p, 720P 50HZ, 720P 60HZ, 1080i 50Hz, 1080i 60HZ, 1080P 50HZ, 1080P 60HZ
    • Transmission distance: up to 300 meters at 1080p @ 60Hz with a proper electric power plant
    • Infrared remote control: supports 20 ~ 60KHZ
    • Input voltage: 100 / 240V AC
    • Power consumption: 7W
    • Housing material: plastic non-combustible
    • Safety against electrical damage: coupling circuit with fuse and ESD protection, tested for 24 days, 7 hours of work a day

    Dimensions
    • Width 150 mm
    • Height 25 mm
    • Depth 92.7 mm

    Package Contents
    • 1x Receiver extender
    • 1x Power Cable 100 / 240V AC
    • 1x IR Receiver
    • 1x User Manual
    data sheet
    generale
    Brand
    Techly Np
    Barcode
    8054529021628
    Color
    No
    Codice Fornitore
    021628
    input
    Connector A Type
    C7 - 2 poles
    format A connector
    male
    Number A Connector
    1
    Altri Connettori Input
    Ingresso IR
    output
    Connector B Type
    HDMI
    format B connector
    female
    Number B Connector
    1
    specifiche tecniche
    Typology
    Amplifier
    Max Video Resolution
    1080p
    max bandwidth (MHz)
    No
    Deep Color
    No
    HDMI
    No
    HDCP
    Yes
    3D compatible
    No
    Supported audio standards
    Yes
    Transmission Distance
    300 m
    alimentazione
    Power supply
    Not required
    dimensioni
    Width
    150 mm
    Height
    25 mm
    Depth
    92,7 mm
    Weight
    0.4740
    The package includes
    • 1x Ricevitore extender • 1x Cavo di alimentazione 100/240V AC • 1x Ricevitore IR • 1x Manuale d'uso
