Amplifier / Splitter HDMI Over IP Network with IR Control - TECHLY - IDATA EXTIP-373IR-1
Techly

Amplifier / Splitter HDMI Over IP Network with IR Control

Cod: IDATA EXTIP-373IR
Copied!
Tipo connettore A: HDMITipo connettore B: HDMIRisoluzione Video Max: 1080pHDCP: Yes
System of signal transmission professional who can carry an HDMI signal over long distances via a network cable Cat.5 / 6, using the conversion of the HDMI signal into a signal standard TCP / IP. Through a router or a repeater with a cascade connection, the HDMI signal can be extended indefinitely. The IDATA EXTIP-373IR, also allows to carry out function splitter because a transmitter can be connected to N receivers (max 253) to bring the HDMI signal to different screens depending on the user's needs. Supports IR control so the user can easily control the devices from long distances. Supports all HDMI specification including full HD 1080p, Deep Color, Lip Sync and CEC; also supports all popular audio formats including high-resolution multichannel Dolby Digital Plus, LPCM 7.1, Dolby TrueHD and DTS Master Audio.

Characteristics
  • It transmits the audio signal from your local digital video (transmitter) that is connected to the HDMI source to a remote unit (receiver) connected to the screen via network cable
  • Carry your HDMI signal up to 120 m using a network cable Cat.6
  • The local unit if it is connected to several remote units via a switching hub, thus creating links point to multi-point
  • Supports remote control function making it possible for the user to easily manage devices from long distances
Specification
  • Supports HDCP1.2
  • Resolution HDMI input: 480i @ 60Hz 480p @ 60Hz, 576i @ 50Hz 576p @ 50Hz 720p @ 50 / 60Hz, 1080i @ 50 / 60Hz, 1080p @ 50 / 60Hz;
  • Resolution HDMI output: 480p @ 60Hz 576p @ 50Hz 720p @ 50 / 60Hz, 1080p @ 50 / 60Hz
  • Color Format Video Support: 24bit / 30bit Deep color / Deep color 36bit
  • supported audio format: DTS-HD / Dolby True-HD / LPCM7.1 / DTS / Dolby-AC3 / DSD
  • Max Transmission Speed​​: 10.2Gbps
  • TMDS signal: 0.5-1.5Vp-p (TMDS)
  • DDC Signal: 5Vp-p (TTL)
  • Cable length input: ≤5m (High Speed ​​HDMI Cable AWG26)
  • Length of output cable: ≤5m (High Speed ​​HDMI Cable AWG26)
  • Connector Type: RJ45
  • Interface: Cat5e / 6 twisted pair
  • Transmission distance: up to 120m Cat6 cable (Cat5e up to 100m)
  • Wiring Standard: TIA / EIA568 B
  • Power supply: DC5V
  • Power consumption: <3.6W
  • Operating temperature: 0-55 ℃
  • Storage temperature: -20 - 70 ℃ (non-condensing)
  • Dimensions (WxDxH): 13 x 8.6 x 2.5 cm
Package Contents
  • Transmitter x 1
  • Receiver x 1
  • Extension 1 x IR Blaster
  • Extension IR receiver x 1
  • Power x 2
  • Instruction manual
Description Data sheet Reviews Drivers & manuals
Cod: IDATA EXTIP-373IR
Barcode: 8057685306028

Supplier Code: 306028

Weight: 0.805 Kg
Min. sale unit: 1 Pcs
Package pcs: 20 Pcs
Cod
IDATA EXTIP-373IR
Barcode
8057685306028
Supplier Code
306028
Weight
0.805 Kg
Min. sale unit
1 Pcs
Package pcs
20 Pcs
NO LONGER AVAILABLE
This product has been replaced by IDATA EXTIP-383IR, or search in the category Audio Video Extender for a product that meets your needs.
Go to category
Alternative products
Description
System of signal transmission professional who can carry an HDMI signal over long distances via a network cable Cat.5 / 6, using the conversion of the HDMI signal into a signal standard TCP / IP. Through a router or a repeater with a cascade connection, the HDMI signal can be extended indefinitely. The IDATA EXTIP-373IR, also allows to carry out function splitter because a transmitter can be connected to N receivers (max 253) to bring the HDMI signal to different screens depending on the user's needs. Supports IR control so the user can easily control the devices from long distances. Supports all HDMI specification including full HD 1080p, Deep Color, Lip Sync and CEC; also supports all popular audio formats including high-resolution multichannel Dolby Digital Plus, LPCM 7.1, Dolby TrueHD and DTS Master Audio.

Characteristics
  • It transmits the audio signal from your local digital video (transmitter) that is connected to the HDMI source to a remote unit (receiver) connected to the screen via network cable
  • Carry your HDMI signal up to 120 m using a network cable Cat.6
  • The local unit if it is connected to several remote units via a switching hub, thus creating links point to multi-point
  • Supports remote control function making it possible for the user to easily manage devices from long distances
Specification
  • Supports HDCP1.2
  • Resolution HDMI input: 480i @ 60Hz 480p @ 60Hz, 576i @ 50Hz 576p @ 50Hz 720p @ 50 / 60Hz, 1080i @ 50 / 60Hz, 1080p @ 50 / 60Hz;
  • Resolution HDMI output: 480p @ 60Hz 576p @ 50Hz 720p @ 50 / 60Hz, 1080p @ 50 / 60Hz
  • Color Format Video Support: 24bit / 30bit Deep color / Deep color 36bit
  • supported audio format: DTS-HD / Dolby True-HD / LPCM7.1 / DTS / Dolby-AC3 / DSD
  • Max Transmission Speed​​: 10.2Gbps
  • TMDS signal: 0.5-1.5Vp-p (TMDS)
  • DDC Signal: 5Vp-p (TTL)
  • Cable length input: ≤5m (High Speed ​​HDMI Cable AWG26)
  • Length of output cable: ≤5m (High Speed ​​HDMI Cable AWG26)
  • Connector Type: RJ45
  • Interface: Cat5e / 6 twisted pair
  • Transmission distance: up to 120m Cat6 cable (Cat5e up to 100m)
  • Wiring Standard: TIA / EIA568 B
  • Power supply: DC5V
  • Power consumption: <3.6W
  • Operating temperature: 0-55 ℃
  • Storage temperature: -20 - 70 ℃ (non-condensing)
  • Dimensions (WxDxH): 13 x 8.6 x 2.5 cm
Package Contents
  • Transmitter x 1
  • Receiver x 1
  • Extension 1 x IR Blaster
  • Extension IR receiver x 1
  • Power x 2
  • Instruction manual
Reviews
Data sheet
general
Brand TECHLY Barcode 8057685306028
Color Black Codice Fornitore 306028
input
Connector A Type HDMI format A connector female
Number A Connector 1 Altri Connettori Input 1x Lan RX input 1x Alimentazione 5V DC
output
Connector B Type HDMI format B connector female
Number B Connector 1
technical specifications
Typology Amplifier, Splitter Max Video Resolution 1080p
max bandwidth (MHz) - Deep Color 36 bit
HDMI - HDCP Yes
3D compatible No Supported audio standards Yes
Transmission Distance 120 m
power supply
Power supply Requested (included)
dimensions
Width 13 cm Height 2.5 cm
Depth 8.6 cm Weight 0.8050
The package includes • Trasmettitore x 1 • Ricevitore x 1 • Prolunga IR Blaster x 1 • Prolunga ricevitore IR x 1 • Alimentatore x 2 • Manuale d'istruzioni
