Fiber Optic Cable LC/LC 9/125 Singlemode 3m Diameter 1.2mm OS2
Code: ILWL OS212-LCLC-030T    Barcode: 8051128102468

   Supplier Code: 102468

Available

Fiber Optic Cable LC/LC 9/125 Singlemode 3m Diameter 1.2mm OS2

Certificazioni: RoHS
Anni di Garanzia: 3
Core Cavo Fibra: 9/125 MonoMod OS2
Rivestimento cavo: LSZH
Diametro cavo: 1.2 mm
Choose a different Option:

• OS2: 9/125 single-mode fiber cable used in networking over large areas or backbone applications between buildings with a maximum distance of 40 km
• Connectors: LC to LC
• Duplex
• Fiber diameters - Core: 9 microns; Coatings: 125 microns
• Type of fiber: single-mode
• Length: 3m

    Description

    Details

    • Compatible with multimode fiber applications
    • High bandwidth to support longer distances
    • Economic solution
    • Ideal for use in Gigabit Ethernet applications
    • Halogen-free and flame-retardant according to IEC-60754-2, IEC-60332-1 and IEC-61034

    Features
    • Fiber diameters - Core: 9 microns; Coatings: 125 microns
    • type of fiber - Singlemode
    • OS2: 9/125 single-mode fiber cable used in networking over large areas or backbone applications between buildings with a maximum distance of 40 km
    • Connectors: LC to LC
    • LC connector in compact design
    • The connectors meet the quality class of single-mode A / 1 grade according to IEC-61753-122-2
    • Duplex
    • Coating: PVC
    • Jacket OD: 1.2 mm
    • Color coating: Yellow
    • Length: 3m
    data sheet
    generale
    Brand
    Techly Professional
    Barcode
    8051128102468
    Weight
    0.0320
    Certifications
    RoHS
    Years of Warranty
    3
    Codice Fornitore
    102468
    specifiche tecniche
    Fiber connector
    LC/LC
    Core Cable Fiber
    9/125 MonoMod OS2
    Fiber number
    2
    Cable sheath
    LSZH
    Length
    3 m
    Cable diameter
    1.2 mm
    Color
    Yellow
    CPR
    No
    connessioni
    Connector A Type
    LC Duplex
    Connector B Type
    LC Duplex
    format A connector
    male
    format B connector
    male
