HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE - TECHLY - IDATA EXT-E70POE-1
HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE - TECHLY - IDATA EXT-E70POE-1
HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE - TECHLY - IDATA EXT-E70POE-0
HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE - TECHLY - IDATA EXT-E70POE-1
HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE - TECHLY - IDATA EXT-E70POE-2
HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE - TECHLY - IDATA EXT-E70POE-3
+3
HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE - TECHLY - IDATA EXT-E70POE-1
Techly

HDMI Extender Full HD over Network cable Cat.6/6A/7 with POE

Cod: IDATA EXT-E70POE

Barcode: 8054529028221

Supplier Code: 028221

Weight: 0.448 Kg

Min. sale unit: 1 Pcs

Package pcs: 20 Pcs

Cod
IDATA EXT-E70POE
Barcode
8054529028221
Supplier Code
028221
Weight
0.448 Kg
Min. sale unit
1 Pcs
Package pcs
20 Pcs
Certificazioni: CE
Certificazioni: RoHS
Tipo connettore A: HDMI
Tipo connettore B: HDMI
HDCP: Yes
Compatibile 3D: Yes
  • This HDMI extender transmits HDMI signal from the source up to 40m to your HD display over single CAT6/6a/7
  • Only one power adapter is needed for the transmitter, and the receiver can be powered by the transmitter over network cable
  • The highest resolutions supported is up to 1080P@60Hz
  • Transmission distance: up to 40m
  • Support IR pass back function
  • Uncompressed and zero latency
  • Compliant to HDCP
  • Auto adjustment to match cable length
  • Dimension: 71.6 x 66.6 x 22.6 mm; Color: black
Description
  • This HDMI extender transmits HDMI signal from the source up to 40m to your HD display over single CAT6/6a/7
  • Only one power adapter is needed for the transmitter, and the receiver can be powered by the transmitter over network cable
  • The highest resolutions supported is up to 1080P@60Hz
  • Support IR pass back function
  • Uncompressed and zero latency
Specification
  • Resolution supported: 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
  • Network cable: Cat.6/6A/7copper cable
  • Transmission distance: up to 40m
  • Highest resolutions supported: Full HD 1080p@60Hz
  • Supports IR pass back function
  • Supports 20~60kHz wide frequency IR remote device
  • Auto adjustment to match cable length
  • Compliant to HDCP
  • Power consumption: TX: < 3W; RX: < 3W
Dimension
  • Width: 71.6 mm
  • Depth: 66.6 mm
  • Height: 22.6 mm
Certification
  • CE
  • RoHS
  • RAEE
Package contents
  • 1x Trasmitter (TX) from HDMI to LAN
  • 1x Receiver (RX) from LAN to HDMI
  • 2x Power supply DC 5V/2A
  • 1x User's manual
Data sheet
general
Brand TECHLY Barcode 8054529028221
Certifications CE , RoHS Color -
Codice Fornitore 028221
input
Connector A Type HDMI format A connector female
Number A Connector 1 Altri Connettori Input RJ45 Femmina 1
output
Connector B Type HDMI format B connector female
Number B Connector 1 Altri Connettori Output RJ45 Femmina 1
technical specifications
Typology Amplifier Max Video Resolution Full HD 1920 x 1080
max bandwidth (MHz) 225 MHz Deep Color -
HDMI 1.3 HDCP Yes
3D compatible Yes Supported audio standards Uncompressed
Transmission Distance 40 m
power supply
Power supply Requested (included) Consumo energetico TX: <3W - RX: <3W
dimensions
Width 71.6 mm Height 22.6 mm
Depth 66.6 mm Weight 0.4480
The package includes • 1x Trasmettitore (TX) da HDMI a LAN • 1x Ricevitore (RX) da LAN a HDMI • 2x Alimentatore DC 5V/2A • 1x Manuale d’istruzione
Drivers & manuals
