HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m - TECHLY - ICOC HDMI-4-EXT018-1
HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m - TECHLY - ICOC HDMI-4-EXT018-1
HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m - TECHLY - ICOC HDMI-4-EXT018-0
HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m - TECHLY - ICOC HDMI-4-EXT018-1
HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m - TECHLY - ICOC HDMI-4-EXT018-2
HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m - TECHLY - ICOC HDMI-4-EXT018-3
HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m - TECHLY - ICOC HDMI-4-EXT018-1
Techly

HDMI High Speed with Ethernet Extension Cable 4K 30Hz M/F 1.8 m

Cod: ICOC HDMI-4-EXT018

Barcode: 8051128106350

Supplier Code: 106350

Weight: 0.121 Kg

Min. sale unit: 1 Pcs

Package pcs: 80 Pcs

Cod
ICOC HDMI-4-EXT018
Barcode
8051128106350
Supplier Code
106350
Weight
0.121 Kg
Min. sale unit
1 Pcs
Package pcs
80 Pcs
Certificazioni: CE
Certificazioni: UL
Certificazioni: RoHS
Anni di Garanzia: 3
Tipo connettore B: HDMI-A
Connettori dorati: Yes
Risoluzione massima: 4K (2160p) 30fps
Altri Standard Supportati: 3D
Altri Standard Supportati: HDCP
  • HDMI 19-pin male to HDMI 19-pin female
  • Ensures signal integrity between HDMI devices
  • Supports HDMI Ethernet, Audio Return, 3D Video, 4K @ 30Hz video resolution and Deep Color
  • Conforms to HDMI High Speed specifications with Ethernet
  • Up to 10.2 Gbps at 340 MHz bandwidth
  • Fully shielded to reduce electromagnetic interference (EMI) and other sources of interference
  • Length: 1.8 m
Description
  • HDMI 19-pin male to HDMI 19-pin female
  • Ensures signal integrity between HDMI devices
  • Supports HDMI Ethernet, Audio Return, 3D Video, 4K @ 30Hz video resolution and Deep Color
  • Conforms to HDMI High Speed ​​specifications with Ethernet
  • Up to 10.2 Gbps at 340 MHz bandwidth
  • Fully shielded to reduce electromagnetic interference (EMI) and other sources of interference
  • Die-cast PVC connector cover
Standards and certifications:
  • UL 20276
  • RoHS
  • EC
General Information:
  • Bandwidth: 10.2 Gbps
  • 340 MHz
  • Compliant or superior to existing HDMI standards
  • Length: 1.8 m
Contacts
  • 1 x HDMI 19-pin male
  • 1 x HDMI 19-pin female
  • Gold contacts
  • PVC die-cast connector covers
  • Shielded, braided and aluminum foil
  • 30 AWG connectors
Electrical Information:
  • Current index: 0.5 A DC
  • Withstanding voltage: 300 V DC
  • Insulation resistance: 10 MOhms
  • Conductive resistance: 2 Ohms
Package Contents:
  • High Speed ​​HDMI extension cable with Ethernet M / F 1.8 m
Data sheet
general
Brand TECHLY Barcode 8051128106350
Weight 0.1210 Certifications CE , UL, RoHS
Years of Warranty 3 Codice Fornitore 106350
specifications
Typology HDMI High Speed con Ethernet Length 1,8 m
Connector A Type HDMI-A format A connector male
Connector B Type HDMI-A format B connector male
Headphone connectors Yes Cable shielding Doble
Shielding type Braid and aluminum foil Cable size (AWG) 28
Color Black
technical specifications
Cable rate 340 MHz Maximum resolution 4K (2160p) 30fps
Maximum bandwidth per channel 10 Gbit/s Color space support Deep Color
Audio Standard Supportati Audio-Return Channel (ARC), Dolby Digital/Plus , Dolby TrueHD , DTS-HD Master Audio , DVD-Audio , SA-CD Other Standards Supported 3D , HDCP , HEC (HDMI Ethernet Channel), Ultra HD 4K (2160i/p)
