HDMI Splitter 8 Port 340 MHz band Full 3D 4K*2K
Code: IDATA HDMI-8SPU    Barcode: 8057685305458

   Supplier Code: 305458

NO LONGER AVAILABLE

HDMI Splitter 8 Port 340 MHz band Full 3D 4K*2K

Certificazioni: CE
Certificazioni: FCC
Certificazioni:
Tipo connettore A: HDMI
Tipo connettore B: HDMI
Risoluzione Video Max: Ultra HD 4K 2160p
HDCP: Yes
Choose a different Option:

• This HDMI splitter allows you to duplicate and distribute the signal from an HD video source simultaneously on eight TV or eight HD monitor
• Supports all HDMI devices such as DVD players, HD-TV, satellite decoder / DDT, PS3, Xbox 360 and Blu-ray
• Great to distribute the signal of one device on 8 different HDMI monitor HD - TV.
• The signal is played back simultaneously and parallel audio and video
• Ideal for use in conference rooms, classrooms and corporate training
• Compliance with HDCP 1.3 to protect the transmission of high-definition content and the assurance of receiving quality
• Installs in seconds and requires no configuration
• Supports uncompressed audio such as LPCM
• Supports compressed audio such as DTS Digital, Dolby Digital (including DTS-HD and Dolby True HD)
• Supports full 3D and 4K * 2K

Connections
• 1 Input DDC Signal: 5 V
• 1 HDMI input F
• 8 outputs HDMI F

Operating Frequency
• Frequency Range: 50 / 60Hz
• Video Amplifier Bandwidth: 3.4Gbps / 340MHz

Resolutions (HDTV)
• Interlaced (50-60Hz): 480i, 576i, 1080i
• Progressive (50-60Hz): 480p, 576p, 720p, 1080p, 4K * 2K

Environmental Characteristics
• Operating temperature: 0 ℃ to + 70 ℃
• Operating Humidity: 10% to 85% RH (non-condensing)
• Storage temperature: -10 ℃ to + 80 ℃
• Storage humidity: 5% to 90% RH (non-condensing)

Power Requirements
• Power supply: 5V DC @ 4A
• Power Consumption (Max): 16W

Dimensions
• Width 257 mm
• Depth 120 mm
• Height 25 mm

Certifications
• EC
• FCC
• WEEE
• UL

Package Contents
• 8-way HDMI Splitter
• Power
• Owner's Manual

Description

Details

• This HDMI splitter allows you to duplicate and distribute the signal from an HD video source simultaneously on eight TV or eight HD monitor
• Supports all HDMI devices such as DVD players, HD-TV, satellite decoder / DDT, PS3, Xbox 360 and Blu-ray
• Great to distribute the signal of one device on 8 different HDMI monitor HD - TV.
• The signal is played back simultaneously and parallel audio and video
• Ideal for use in conference rooms, classrooms and corporate training
• Compliance with HDCP 1.3 to protect the transmission of high-definition content and the assurance of receiving quality
• Installs in seconds and requires no configuration
• Supports uncompressed audio such as LPCM
• Supports compressed audio such as DTS Digital, Dolby Digital (including DTS-HD and Dolby True HD)
• Supports full 3D and 4K * 2K

Connections
• 1 Input DDC Signal: 5 V
• 1 HDMI input F
• 8 outputs HDMI F

Operating Frequency
• Frequency Range: 50 / 60Hz
• Video Amplifier Bandwidth: 3.4Gbps / 340MHz

Resolutions (HDTV)
• Interlaced (50-60Hz): 480i, 576i, 1080i
• Progressive (50-60Hz): 480p, 576p, 720p, 1080p, 4K * 2K

Environmental Characteristics
• Operating temperature: 0 ℃ to + 70 ℃
• Operating Humidity: 10% to 85% RH (non-condensing)
• Storage temperature: -10 ℃ to + 80 ℃
• Storage humidity: 5% to 90% RH (non-condensing)

Power Requirements
• Power supply: 5V DC @ 4A
• Power Consumption (Max): 16W

Dimensions
• Width 257 mm
• Depth 120 mm
• Height 25 mm

Certifications
• EC
• FCC
• WEEE
• UL

Package Contents
• 8-way HDMI Splitter
• Power
• Owner's Manual
data sheet
generale
Brand
Techly
Barcode
8057685305458
Certifications
CE , FCC , UL
Color
Black
Codice Fornitore
305458
input
Connector A Type
HDMI
format A connector
female
Number A Connector
1
Altri Connettori Input
1 connettore 5V
output
Connector B Type
HDMI
format B connector
female
Number B Connector
8
specifiche tecniche
Typology
Splitter
Max Video Resolution
Ultra HD 4K 2160p
max bandwidth (MHz)
340 MHz
Deep Color
12 bit
HDCP
Yes
3D compatible
Yes
Supported audio standards
Compressed, not compressed
alimentazione
Power supply
Requested (included)
Consumo energetico
12W
dimensioni
Width
257 mm
Height
25 mm
Depth
120 mm
Weight
1.2850
The package includes
• Splitter 8 vie HDMI • Alimentatore • Manuale d'uso
