High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black - TECHLY - ICOC HDMI-4-250-1
High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black - TECHLY - ICOC HDMI-4-250-1
High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black - TECHLY - ICOC HDMI-4-250-0
High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black - TECHLY - ICOC HDMI-4-250-1
High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black - TECHLY - ICOC HDMI-4-250-2
High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black - TECHLY - ICOC HDMI-4-250-3
+2
High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black - TECHLY - ICOC HDMI-4-250-1
Techly

High Speed HDMI Cable with Ethernet A/A M/M 4K 25m Black

Cod: ICOC HDMI-4-250

Barcode: 8057685304512

Supplier Code: 304512

Weight: 4.095 Kg

Min. sale unit: 1 Pcs

Package pcs: 4 Pcs

Available
Limited time offer!

Incl. Tax: €150.00

Excl. Tax: €122.95 + VAT

Cod
ICOC HDMI-4-250
Barcode
8057685304512
Supplier Code
304512
Weight
4.095 Kg
Min. sale unit
1 Pcs
Package pcs
4 Pcs
Find HDMI Cables
right for you
Configure now
Shipping from €6.50 VAT excluded
Order now and we'll ship on June the 24th
Made easy
Secure payments
Certificazioni: EC
Certificazioni: RoHS
Anni di Garanzia: 3
Tipo connettore A: HDMI-A
Tipo connettore B: HDMI-A
Connettori dorati: Yes
Risoluzione massima: 4K (2160p) 30fps
Altri Standard Supportati: 3D
Altri Standard Supportati: Full HD (1080i/p)
Altri Standard Supportati: HD ready (720i/p)
Altri Standard Supportati: HDCP
  • High Speed HDMI™ cable with Ethernet M/M 25 metres; HDMI™ A 19-pin / HDMI™ A 19-pin gold connectors
  • Supports internet connection via HDMI™ (HEC); Maximum resolution: Ultra HD 4K@30Hz
  • 3D support with resolution over 1080p and Deep Color
  • Audio Return Channel (ARC) support
  • High-speed, two-way communication up to 100 Mbps
Description
  • Cable based on a new technology that offers the best data transmission between HDMI™ source and HDMI™ display. The five twisted pairs offer better data transmission between devices
  • Triple shielded with rugged connectors for better performance that optimizes signal with data integrity, even in installation environments subject to the worst EMS interference
  • All cable materials are 100% RoHS compliant and lead free
  • HDMI™ 19-pin male to HDMI™ 19-pin male connections
  • High-speed, two-way communication up to 100 Mbps
  • Supports HD resolutions over 1080p and Deep Color
  • Compliant with HDMI™ High Speed specifications
  • Connector cover in die-cast PVC
  • HDMI™ Ethernet Channel: supports internet connection via HDMI™ (HEC)
  • Channel Audio Return: Enables an HDMI™ connected TV with a built-in tuner to send audio data 'upstream' to a surround sound system, eliminating the need for a separate audio cable
  • Supports 3D: defines input / output protocols for major 3D video formats, including for games and home theater 3D applications
  • Supports Ultra HD 4K@30Hz resolution: Enables video resolutions far beyond 1080p, supports next generation displays
General information
  • Supports HEC
  • Length: 25 meters
Connectors
  • 2 x HDMI™ 19-pin male
  • Gold plated contacts
  • PVC die-cast connector covers
  • Shielded, braided and aluminum foil
  • 22 AWG connectors
  • Cable diameter: 12.0 mm
Electrical information
  • Current rating: 0.5A DC
  • Supports 300V DC voltage
  • Insulation resistance: 50 MOhms
  • Conductive resistance: 2 Ohms
Standards and Certifications
  • UL 20276
  • ISO 9002
  • UK
Box Contents
  • High Speed HDMI™ cable with Ethernet Channel 25 metres
Data sheet
general
Brand TECHLY Barcode 8057685304512
Weight 4.0950 Certifications EC, RoHS
Years of Warranty 3 Codice Fornitore 304512
specifications
Typology HDMI High Speed with Ethernet Length 25 m
Connector A Type HDMI-A format A connector male
Connector B Type HDMI-A format B connector male
Headphone connectors Yes Cable shielding Doble
Shielding type Braid and aluminum foil Cable size (AWG) 22
Color Black
technical specifications
Cable rate 340 MHz Maximum resolution 4K (2160p) 30fps
Maximum bandwidth per channel 10 Gbit/s Audio Standard Supportati Dolby Digital/Plus , Dolby TrueHD , DTS-HD Master Audio , DVD-Audio , SA-CD
Other Standards Supported 3D , CEC , Full HD (1080i/p) , HD ready (720i/p) , HDCP , HEC (HDMI Ethernet Channel), SDTV (480i/p), Ultra HD 4K (2160i/p)
