USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections - TECHLY - IADAP USB31-DOCK2-1
USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections - TECHLY - IADAP USB31-DOCK2-1
USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections - TECHLY - IADAP USB31-DOCK2-0
USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections - TECHLY - IADAP USB31-DOCK2-1
USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections - TECHLY - IADAP USB31-DOCK2-2
USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections - TECHLY - IADAP USB31-DOCK2-1
Techly
A corto di porte? Ecco come rimediare Watch the video

USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections

Cod: IADAP USB31-DOCK2

Barcode: 8051128102093

Supplier Code: 102093

Weight: 0.086 Kg

Min. sale unit: 1 Pcs

Package pcs: 40 Pcs

Cod
IADAP USB31-DOCK2
Barcode
8051128102093
Supplier Code
102093
Weight
0.086 Kg
Min. sale unit
1 Pcs
Package pcs
40 Pcs
Certificazioni: CE
Certificazioni: RoHS
Tipologia: USB
USB standard: USB 3.0
Windows 7: Yes
Windows 8: Yes
Windows 10: Yes
Mac: Yes
  • Supports resolution up to 1920 x 1200 60Hz
  • Input: USB-C Male x1
  • Input: USBC-C Female x1 (for charging)
  • Output: VGA Female x1
  • Output: RJ45X1
  • Output: USB-A Female x1
  • Vertical frequency 50/60Hz - Bandwidth up to 2.25Gbps/225MHz
  • Color: white
Description
IADAP USB31-DOCK2 is a USB-C to USB 3.0 with Gigabit Ethernet, VGA and USB-C charging port hub. The USB 3.0 port allows you to connect a USB device to a host
computer or another hub, the USB-C female port can charge for the host computer, VGA port allows you to connect a VGA monitor so that you can watch videos or
slideshows on a big screen and the host computer can easily connect to the network through the Gigabit Ethernet port. It can work on Macbook or Google new Chromebook Pixel and other USB-C supported devices.

Features
  • USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections
  • Supports resolution up to 1920 x 1200 60Hz
  • Input: USB-C Male x1
  • Input: USBC-C Female x1 (for charging)
  • Output: VGA Female x1
  • Output: RJ45X1
  • Output: USB-A Female x1
  • Vertical frequency 50/60Hz - Bandwidth up to 2.25Gbps/225MHz
  • Color: white
Technical specificationsg
  • Support USB-C, VGA, USB3.0, Gigabit Ethernet port
  • Support USB 3.0 super speed (5Gbps) transmission, downward compatible with USB2.0
  • USB 3.0 port supports to charge and transmit data for the USB device simultaneously
  • Support BC1.2, the power of USB-A port can be up to 7.5W (5V/1.5A)
  • Support VGA resolution up to 1920X1200@60Hz
  • Support 10/100 /1000Mbps bandwidth
  • Support twisted pair crossover detection and auto-correction
  • USB-C charging port supports to charge for Macbook or Google new Chromebook Pixel and other USB-C supported devices and supply power for the hub
  • Multiple USB-C interfaces support plug and play, hot swap
Dimensions
  • Lenght: 95 mm
  • Width: 41 mm
  • Height: 17 mm
  • Weight: 46.9 gr
Power Supply
  • USB3.0 port: up to 7.5W (5V/1.5A)
  • USB-C Female: up to 60W (20V/3A)
Environmental characteristics
  • Operating Temperature: 0°C to +45°C
  • Operating Humidity: 10% to 85 % RH (no condensation)
  • Storage Temperature: -10°C to +80°C
  • Storage Humidity: 5% to 90 % RH (no condensation)
Certifications
  • FCC
  • CE
  • RAEE
Package Contents
  • USB 3.1 Type-C adapter to USB3.0, with VGA, RJ45, Type-C connections
  • User Manual
Data sheet
general
Brand TECHLY Barcode 8051128102093
Color White Certifications CE , RoHS
Codice Fornitore 102093
technical features
Typology USB USB speed 5 Gbit/s
USB 2.0 ports 1 USB 3.2 ports 1
USB standard USB 3.0 Supply internal USB
Voltage - Other Features • Ingresso: USB-C™ maschio x 1 • Ingresso: USBC-C™ femmina x 1 (per ricarica) • Uscita: VGA femmina x 1 • Uscita: RJ45 x 1 • Uscita: USB-A femmina x 1
Altro contenuto della confezione • Adattatore USB-C™ a USB-A 3.0 con connessioni VGA, RJ45, USB-C™ • Manuale d’istruzione
compatibility
Windows 98 - Windows 2000 -
Windows XP - Windows Vista Yes
Windows 7 Yes Windows 8 Yes
Windows 10 Yes Windows 11 -
Mac Yes Linux -
dimensions
Height 95 mm Width 41 mm
Depth 17 mm Weight 0.0860
Drivers & manuals
