Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5 - TECHLY - I-WL-REPEATER5-1
Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5 - TECHLY - I-WL-REPEATER5-1
Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5 - TECHLY - I-WL-REPEATER5-0
Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5 - TECHLY - I-WL-REPEATER5-1
Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5 - TECHLY - I-WL-REPEATER5-2
Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5 - TECHLY - I-WL-REPEATER5-3
+2
Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5 - TECHLY - I-WL-REPEATER5-1
Techly
Techly Repeater AC750: Potenziare la Connessione WiFi Watch the video

Wall Plug WiFi Mini Router 750Mbps Dual Band Repeater5

Cod: I-WL-REPEATER5

Barcode: 8057685309999

Supplier Code: 309999

Weight: 0.231 Kg

Min. sale unit: 1 Pcs

Package pcs: 50 Pcs

Cod
I-WL-REPEATER5
Barcode
8057685309999
Supplier Code
309999
Weight
0.231 Kg
Min. sale unit
1 Pcs
Package pcs
50 Pcs
Certificazioni: CE
Certificazioni: FCC
Certificazioni:
Funzione Tasto WPS: Yes
Windows 7: Yes
Windows 8: Yes
Mac: Yes
Linux: Yes
I-WL-REPEATER5 repeater is a mini wall that supports the latest wireless technology with speeds up to 750 Mbps, up to 433 Mbps on the 5 GHz frequency range and up to 300 Mbps on the 2.4 GHz frequency. The simultaneous dual band operation (2.4 GHz and 5 GHz) provides double the bandwidth.

Features
  • Increase the Wi-Fi signal and eliminates any points not covered by wireless signal
  • Simple installation - no drivers required software
  • Ideal for use with smartphones, tablets and any wireless device
  • Work with your existing wireless network at home
  • ultra fast wireless connection for gaming and HD quality streaming media without latencies
  • Reduce the use of data connection 3G / 4G
  • The button for Wi-Fi Protected Setup (WPS) simplifies secure connectivity to the wireless network
  • Supports WMM (IEEE 802.11e QoS standard) prioritizing bandwidth for multimedia applications
  • Supports WEP (64/128 bit), WPA and WPA2
  • it Can also be used as a wireless access point or wireless router standard
  • Use Techly Wireless WLAN adapters and AC adapters for the best compatibility and performance
Standard
  • IEEE 802.11ac (433 Mbps Wireless LAN)
  • IEEE 802.11b (11 Mbps Wireless LAN)
  • IEEE 802.11g (54 Mbps Wireless LAN)
  • IEEE 802.11n (300 Mbps Wireless LAN)
General information:
  • LAN port: RJ45 10/100 Mbps
  • WAN Port: RJ45 10/100 Mbps
Button
  • WPS / Reset
  • Mode 'operation:
- Access Point / Repeater
- Router
  • Flash memory: 16 MB
  • SDRAM: 128 MB
Wireless
  • 5.0 GHz Wireless Speed: up to 433 Mbps
  • 2.4 GHz Wireless Speed: up to 300 Mbps
  • Wireless Security:
- WEP encryption (64/128 bit)
- WPA TKIP
- WPA2 AES
- WPA2 mixed

Supply
  • Input: 100-240 VAC, 50-60 Hz
  • Internal 110-230 VAC, 50-60 Hz
  • Power: 3.3 Watts max
Dimensions
  • Width 78 mm
  • Depth 62.3 mm
  • Height 60 mm
  • Weight: 0.24kg
Certifications
  • EC
  • FCC Class B
  • RoHS
  • WEEE
Package Contents
  • Wireless Repeater
  • Quick Installation Guide
  • Installation CD
  • Network cable RJ45 Cat5 1m
Description
I-WL-REPEATER5 repeater is a mini wall that supports the latest wireless technology with speeds up to 750 Mbps, up to 433 Mbps on the 5 GHz frequency range and up to 300 Mbps on the 2.4 GHz frequency. The simultaneous dual band operation (2.4 GHz and 5 GHz) provides double the bandwidth.

Features
  • Increase the Wi-Fi signal and eliminates any points not covered by wireless signal
  • Simple installation - no drivers required software
  • Ideal for use with smartphones, tablets and any wireless device
  • Work with your existing wireless network at home
  • ultra fast wireless connection for gaming and HD quality streaming media without latencies
  • Reduce the use of data connection 3G / 4G
  • The button for Wi-Fi Protected Setup (WPS) simplifies secure connectivity to the wireless network
  • Supports WMM (IEEE 802.11e QoS standard) prioritizing bandwidth for multimedia applications
  • Supports WEP (64/128 bit), WPA and WPA2
  • it Can also be used as a wireless access point or wireless router standard
  • Use Techly Wireless WLAN adapters and AC adapters for the best compatibility and performance
Standard
  • IEEE 802.11ac (433 Mbps Wireless LAN)
  • IEEE 802.11b (11 Mbps Wireless LAN)
  • IEEE 802.11g (54 Mbps Wireless LAN)
  • IEEE 802.11n (300 Mbps Wireless LAN)
General information:
  • LAN port: RJ45 10/100 Mbps
  • WAN Port: RJ45 10/100 Mbps
Button
  • WPS / Reset
  • Mode 'operation:
- Access Point / Repeater
- Router
  • Flash memory: 16 MB
  • SDRAM: 128 MB
Wireless
  • 5.0 GHz Wireless Speed: up to 433 Mbps
  • 2.4 GHz Wireless Speed: up to 300 Mbps
  • Wireless Security:
- WEP encryption (64/128 bit)
- WPA TKIP
- WPA2 AES
- WPA2 mixed

Supply
  • Input: 100-240 VAC, 50-60 Hz
  • Internal 110-230 VAC, 50-60 Hz
  • Power: 3.3 Watts max
Dimensions
  • Width 78 mm
  • Depth 62.3 mm
  • Height 60 mm
  • Weight: 0.24kg
Certifications
  • EC
  • FCC Class B
  • RoHS
  • WEEE
Package Contents
  • Wireless Repeater
  • Quick Installation Guide
  • Installation CD
  • Network cable RJ45 Cat5 1m
Data sheet
general
Brand TECHLY Barcode 8057685309999
Recommended for No Certifications CE , FCC , RoHS
The package includes • Repeater Wireless • Guida di installazione rapida • CD per l'installazione • Cavo di rete Cat5 RJ45 da 1m Codice Fornitore 309999
connectivity
No. LAN ports 1 No. RJ-45 ports 1
No. WAN ports 1 LAN ports speed 10/100 Mbps
Console port No VLAN support No
Quality of Service (QoS) Yes
wireless
Wireless (standard) 802.11 ac/b/g/n Wireless speed 750 Mbps
Banda di frequenza 2,4 + 5 Ghz Wireless mode Access Point (AP mode), Repeater (Extender), Router
Wireless security WEP , WPA , WPA2 Management interface WEB interface
physical features
Chassis format Wall Indicative led Power , WAN , Wireless , WPS
Color White WPS button function Yes
dimensions
Width 78 mm Height 60 mm
Depth 62.3 mm Weight 0.2310
power supply
Supply external Voltage AC 100-240V
PoE 802.3af support No
compatibility
Windows 98 Yes Windows 2000 Yes
Windows XP Yes Windows Vista Yes
Windows 7 Yes Windows 8 Yes
Mac Yes Linux Yes
Drivers and manuals
