Wireless Router N 300Mbps Poe - TECHLY - I-WL-POE300NT-1
Wireless Router N 300Mbps Poe - TECHLY - I-WL-POE300NT-1
Wireless Router N 300Mbps Poe - TECHLY - I-WL-POE300NT-0
Wireless Router N 300Mbps Poe - TECHLY - I-WL-POE300NT-1
Techly

Wireless Router N 300Mbps Poe

Cod: I-WL-POE300NT

Barcode: 8057685301085

Supplier Code: 301085

Weight: 0.449 Kg

Min. sale unit: 1 Pcs

Package pcs: 20 Pcs

Cod
I-WL-POE300NT
Barcode
8057685301085
Supplier Code
301085
Weight
0.449 Kg
Min. sale unit
1 Pcs
Package pcs
20 Pcs
Certificazioni: CE
Certificazioni: FCC
Certificazioni:
Funzione Tasto WPS: Yes
Supporto poe 802.3af: Yes
The Wireless N Router is a network device wired / wireless combo, designed specifically for small businesses, offices and network requirements for small home studios.
Compliant with the IEEE 802.11n standard with wireless transmission speeds up to 300 Mbps.
The router is equipped with 4 10 / 100Mbps ports to achieve the most effective transmission speed.
The WAN port supports Power over Ethernet (PoE). These PoE ports can automatically detect and receive power from IEEE 802.3af compliant equipment (PSE).
In this situation, the electric current is transmitted along with the data in a single cable allowing you to expand your network even where there is a power line or power outlets.
The Wireless N Router provides numerous safety measures; supporting SSID broadcast control, MAC address access control, WEP encryption, authentication WPA/WPA2 and WPA-PSK/WPA2-PSK.
At the same time QSS (Quick Secure Setup) complies with WPS allowing a security configuration hassle.
These security features combine to protect against intrusion in a stronger and more secure.
Router Wireless-N Router allows companies, offices, and homes to share an Internet connection among multiple computers.
Apart from its wireless function, this Router also features 4 interior interchangeable ports allow you to connect in a convenient way up to 4 computers directly to the router.
Besides the ease of configuration of this product and the most common functions broadband router, also supports the priority of service for which applications that use most of the bandwidth and that are sensitive to interruptions such as voice and video enjoying priority to ensure their quality.
The router also supports the connection request, access management online, the Automatic virus isolation, UPnP, DDNS, the registration system security advanced, easy to use user interface that allows all users to quickly realize the configuration of the router.

Features
  • 2 omni-directional antennas detachable
  • MIMO technology that uses the reflected signal to greatly increase the performance and the amplitude of the transmission
  • Supports PoE IEEE802.3af compliant PSE
  • Complies with IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
  • Supports AP, AP Client, Gateway, WDS working mode
  • WiFi Protected Setup (WPS) simplifies setup and operation
  • Transmission speed up to 300Mbps
  • Provides a port 10/100Mbps Auto-Negotiation Ethernet WAN
  • Provides four-port 10/100Mbps Auto-Negotiation Ethernet LAN
  • Supports functions PPPoE, Dynamic IP and Static
  • Supports UPnP, DDNS, static routing
  • Supports SSID broadcast control and MAC access control list
  • Supports 64/128bit WEP, complies with 128 bit WPA (TKIP / AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X
  • Integrated firewall features IP, MAC, URL filtering which flexibly controls online access and time
  • DHCP server integrated with automatic dynamic IP address distribution
  • WMM and WMM-APSD supported
  • WDS supported with WEP, TKIP and AES encryption
  • Automatic channel Wireless
  • Wireless ISP supported (set the wireless interface on WAN interface)
  • 802.1d spanning tree protocol
  • TCP/UDP/ICMP/ARP protocol stack
  • NAT/NAPT. ALG for FTP, NetMeeting, SIP, VPN pass-through with multiple sessions (IPSEC, L2TP, PPTP)
  • Supports 802.1Q VLAN for Ethernet and wireless
  • The user interface supports free software update via Web
  • Supports configuration file backup and restore
  • smooth outer surface, can be wall mounted or placed horizontally on a table or desk
Specifications
  • Interface: 4-port 10 / 100Mbps LAN; 1 WAN port 10 / 100Mbps
  • Button: Button Quick Setup Security and reset button
  • External power supply: 5 V DC / 1 A
  • Antenna: 2 x 5dBi Omni-directional detachable
  • Wireless Standard: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
  • Frequency: 2.4-2.4835GHz
  • Signal range:
11n: Up to 300Mbps (dynamic)
11g: Up to 54Mbps (dynamic)
11b: Up to 11Mbps (dynamic)
modulation:
11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
11b: DQPSK, DBPSK, DSSS, CCK
  • Power wireless transmission: 14-17dBm
  • Receiving Sensitivity:
270M: -68dBm @ 10% PER
130M: -68dBm @ 10% PER
108M: -68dBm @ 10% PER
54M: -68dBm @ 10% PER
11M: -85dBm @ 8% PER
6M: -88dBm @ 10% PER
1M: -90dBm @ 8% PER
  • Wireless features: Enable / Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
  • Wireless: 64/128/152-bit WEP/WPA/WPA2, WPA-PSK/WPA2-PSK
  • WAN Type: Dynamic IP/Static IP/PPPoE/PPTP/L2TP
  • DHCP: Server, Client, DHCP Client List, Address Reservation
  • Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
  • Quality of Service: WMM
  • Dynamic DNS: DynDns
  • VPN Pass-Throught: PPTP, L2TP, IPSec
  • Access control: Local Management Control, Host List, Access Schedule, Rule Management
  • Security Firewall IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding
  • Operating temperature: 0℃~40℃
  • Storage temperature: -40℃~70℃
  • Dimensions: (WxDxH) 158x105x25 mm
Certifications
CE, FCC, RoHS

Package Contents
  • Belkin N
  • 2 omni-directional detachable antennas
  • Network cable
  • Power supply
  • Guide
Description
The Wireless N Router is a network device wired / wireless combo, designed specifically for small businesses, offices and network requirements for small home studios.
Compliant with the IEEE 802.11n standard with wireless transmission speeds up to 300 Mbps.
The router is equipped with 4 10 / 100Mbps ports to achieve the most effective transmission speed.
The WAN port supports Power over Ethernet (PoE). These PoE ports can automatically detect and receive power from IEEE 802.3af compliant equipment (PSE).
In this situation, the electric current is transmitted along with the data in a single cable allowing you to expand your network even where there is a power line or power outlets.
The Wireless N Router provides numerous safety measures; supporting SSID broadcast control, MAC address access control, WEP encryption, authentication WPA/WPA2 and WPA-PSK/WPA2-PSK.
At the same time QSS (Quick Secure Setup) complies with WPS allowing a security configuration hassle.
These security features combine to protect against intrusion in a stronger and more secure.
Router Wireless-N Router allows companies, offices, and homes to share an Internet connection among multiple computers.
Apart from its wireless function, this Router also features 4 interior interchangeable ports allow you to connect in a convenient way up to 4 computers directly to the router.
Besides the ease of configuration of this product and the most common functions broadband router, also supports the priority of service for which applications that use most of the bandwidth and that are sensitive to interruptions such as voice and video enjoying priority to ensure their quality.
The router also supports the connection request, access management online, the Automatic virus isolation, UPnP, DDNS, the registration system security advanced, easy to use user interface that allows all users to quickly realize the configuration of the router.

Features
  • 2 omni-directional antennas detachable
  • MIMO technology that uses the reflected signal to greatly increase the performance and the amplitude of the transmission
  • Supports PoE IEEE802.3af compliant PSE
  • Complies with IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
  • Supports AP, AP Client, Gateway, WDS working mode
  • WiFi Protected Setup (WPS) simplifies setup and operation
  • Transmission speed up to 300Mbps
  • Provides a port 10/100Mbps Auto-Negotiation Ethernet WAN
  • Provides four-port 10/100Mbps Auto-Negotiation Ethernet LAN
  • Supports functions PPPoE, Dynamic IP and Static
  • Supports UPnP, DDNS, static routing
  • Supports SSID broadcast control and MAC access control list
  • Supports 64/128bit WEP, complies with 128 bit WPA (TKIP / AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X
  • Integrated firewall features IP, MAC, URL filtering which flexibly controls online access and time
  • DHCP server integrated with automatic dynamic IP address distribution
  • WMM and WMM-APSD supported
  • WDS supported with WEP, TKIP and AES encryption
  • Automatic channel Wireless
  • Wireless ISP supported (set the wireless interface on WAN interface)
  • 802.1d spanning tree protocol
  • TCP/UDP/ICMP/ARP protocol stack
  • NAT/NAPT. ALG for FTP, NetMeeting, SIP, VPN pass-through with multiple sessions (IPSEC, L2TP, PPTP)
  • Supports 802.1Q VLAN for Ethernet and wireless
  • The user interface supports free software update via Web
  • Supports configuration file backup and restore
  • smooth outer surface, can be wall mounted or placed horizontally on a table or desk
Specifications
  • Interface: 4-port 10 / 100Mbps LAN; 1 WAN port 10 / 100Mbps
  • Button: Button Quick Setup Security and reset button
  • External power supply: 5 V DC / 1 A
  • Antenna: 2 x 5dBi Omni-directional detachable
  • Wireless Standard: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
  • Frequency: 2.4-2.4835GHz
  • Signal range:
11n: Up to 300Mbps (dynamic)
11g: Up to 54Mbps (dynamic)
11b: Up to 11Mbps (dynamic)
modulation:
11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
11b: DQPSK, DBPSK, DSSS, CCK
  • Power wireless transmission: 14-17dBm
  • Receiving Sensitivity:
270M: -68dBm @ 10% PER
130M: -68dBm @ 10% PER
108M: -68dBm @ 10% PER
54M: -68dBm @ 10% PER
11M: -85dBm @ 8% PER
6M: -88dBm @ 10% PER
1M: -90dBm @ 8% PER
  • Wireless features: Enable / Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
  • Wireless: 64/128/152-bit WEP/WPA/WPA2, WPA-PSK/WPA2-PSK
  • WAN Type: Dynamic IP/Static IP/PPPoE/PPTP/L2TP
  • DHCP: Server, Client, DHCP Client List, Address Reservation
  • Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
  • Quality of Service: WMM
  • Dynamic DNS: DynDns
  • VPN Pass-Throught: PPTP, L2TP, IPSec
  • Access control: Local Management Control, Host List, Access Schedule, Rule Management
  • Security Firewall IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding
  • Operating temperature: 0℃~40℃
  • Storage temperature: -40℃~70℃
  • Dimensions: (WxDxH) 158x105x25 mm
Certifications
CE, FCC, RoHS

Package Contents
  • Belkin N
  • 2 omni-directional detachable antennas
  • Network cable
  • Power supply
  • Guide
Data sheet
general
Brand TECHLY Barcode 8057685301085
Recommended for No Certifications CE , FCC , RoHS
The package includes • Router Wireless N • 2 antenne omni-direzionali staccabili • Cavo di rete • Alimentatore • Guida rapida all'installazione Codice Fornitore 301085
connectivity
No. LAN ports 4 No. RJ-45 ports 4
No. WAN ports 1 LAN ports speed 10/100 Mbps
Console port No VLAN support Yes
Quality of Service (QoS) Yes
wireless
Wireless (standard) IEEE 802.11 b/g/n Wireless speed 300 Mbps
Banda di frequenza 2,4 Ghz Wireless antenna 2 antennas external 5dBi
MIMO technology 2T2R Wireless mode Access Point (AP mode), Client
Wireless functions WDS Bridge , WMM Wireless security WEP , WPA , WPA-PSK , WPA2 , WPA2-PSK
Management interface WEB interface
physical features
Chassis format Desktop Indicative led Power , WAN , WLAN
Color Black WPS button function Yes
dimensions
Width 158 mm Height 25 mm
Depth 105 mm Weight 0.4490
power supply
Supply external Voltage DC 5V
PoE 802.3af support Yes
